表面贴装保险丝薄膜\u003e 0402 \u003e特快熔断\u003e 435系列 Surface Mount Fuses Thin Film > 0402 Size > Very Fast-Acting > 435 Series
AC 直流保险丝 板安装（不包括管筒式） 表面贴装型 0402（1005 公制）
得捷:
FUSE BOARD MNT 375MA 32VDC 0402
立创商城:
0435.375KR
艾睿:
Be protected by adding a chip 0435.375KR fuse developed by Littelfuse. Its maximum power dissipation is 0.03174 W. This device has a maximum power dissipation of 0.03174 W. This device has a current rating of 0.375. This fuse has an operating temperature range of -55 °C to 90 °C. It has 2 terminals. The 0435.375KR fuse has a solder pad termination style. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. Mount your fuse on a printed circuit board using surface mount technology to produce the most effective results. The maximum DC voltage rating is 32 VDC. This product is 1.04Max mm long, 0.38Max mm tall and 0.56Max mm deep. Its fuse is made from epoxy glass.
Chip1Stop:
Fuse Chip Very Fast Acting 0.375A 32V SMD Solder Pad 0402 Epoxy Glass T/R
Newark:
# LITTELFUSE 0435.375KR Fuse, Surface Mount, 435 Series, 375 mA, 32 VDC, Very Fast Acting, 0402
额定电压DC 32 V
额定电流 375 mA
耗散功率 0.03174 W
电阻 0.193 Ω
工作温度Max 90 ℃
工作温度Min -55 ℃
耗散功率Max 0.03174 W
额定电压 32 V
额定电压DC Max 32 V
安装方式 Surface Mount
封装公制 1005
封装 0402
长度 0.991 mm
宽度 0.508 mm
高度 0.38 mm
封装公制 1005
封装 0402
工作温度 -55℃ ~ 90℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
