HARTING 09380062711 连接器嵌件, 母, 矩形, 4路
Han-Com® 插头
极数 4//0, 4//2, 4//8, 6//6, 和 6//12 格式有螺钉连接
极数 8//24 格式有压接
### 注
221-1808 到 221-1791 系列的压接触点利用触点拔插件工具 - 库存号 313-6613。 所有其他产品，使用拔插件工具库存号 114-7728
### 认可
UL，CSA，SEV
### Han-Com® 信号和电源（压接和螺钉）
这些 Han- Com® 插头的电流额定值为 10A 到 100A。 它们旨在结合护套和外壳典型使用；RS 库存号为 181-0561、181-0741、181-0785、363-8535、363-8585 及其相关系列。 这些护罩和外壳系列对应特定的 Harting 尺寸编号标识符
得捷:
INSERT FEMALE 4+0POS+1GND SCREW
欧时:
连接器，电源，大负荷，K 插件，包容式，4/0
贸泽:
Heavy Duty Power Connectors HAN K FEMALE 4/0
e络盟:
重载型连接器, Han Com Series, 插入件, 4触芯, 16B, 插座, 螺丝口
艾睿:
This 09380062711 discrete wire housing from Harting is designed for both small electronic devices as well as larger power applications. This F connector has 4 F contacts. It has a maximum voltage rating of 830 V. It has a straight body orientation. This is a 2-row connector. It has a female type gender. This device has a maximum current rating of 80 A. This product is 120 mm long, 55.6 mm tall and 76 mm deep. This rectangle connector has an operating temperature of -40 to 125 °C. 09380062711 is housed in light gray polycarbonate.
Allied Electronics:
Connector; Power; Heavy Duty; HAN K FEMALE 4/0
TME:
Connector: HAN; female; Han Com; PIN:4; size 16B; 80A; 16mm2
Verical:
Conn Rectangular F 4 POS Screw ST Cable Mount
Newark:
# HARTING 09380062711 Heavy Duty Connector Insert, 4/0+PE Power-Signal, Han-Com Series, Receptacle, 16B, 5 Contacts
