0855055113

模块化插座，直角，低调，全屏蔽， 8/8 ，超五类，通孔，版本A ，管 Modular Jack, Right Angle, Low Profile, Fully Shielded, 8/8, Cat5e, Through Hole, Version A, Tube

模块化 - 插孔 8p8c（RJ45，以太网） 90°角（直角） 屏蔽 Cat5e

得捷:
CONN MOD JACK 8P8C R/A SHIELDED

贸泽:
Modular Connectors / Ethernet Connectors MDJCK 8/8 RA HISP LOPRO TH

艾睿:
A secure connection has never been easier to retain with this rj-45 0855055113 telephone and telecom connector from Molex. This F connector&s;s 8 contacts that are made out of phosphor bronze and plated with gold over nickel. This connector has a single port. It has a maximum voltage rating of 125 VDC. It has a female type gender. It has a right angle body orientation. Its pitch is 2.54 mm. This device has a maximum current rating of 1.5 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This product is 16.6 mm long, 13 mm tall and 18.8 mm deep. 0855055113 is housed in black liquid crystal polymer. This part has an operating temperature of -40 to 85 °C. It uses the solder termination method.

安富利:
Conn RJ-45 RCP 8 POS 2.54mm Solder RA Thru-Hole 8 Terminal 1 Port Tube Cat 5e

Chip1Stop:
Conn RJ-45 F 8 POS 2.54mm Solder RA Thru-Hole 8 Terminal 1 Port Cat 5e Tube

Verical:
Conn RJ-45 F 8 POS 2.54mm Solder RA Thru-Hole 8 Terminal 1 Port Cat 5e Tube
