0015911102

2.54毫米（ .100 ）间距C- Grid®头，表面贴装，双排，垂直， 4回路，锡（Sn ）镀层，无PCB定位器衣夹 2.54mm .100 Pitch C-Grid® Header, Surface Mount, Dual Row, Vertical, 4 Circuits, Tin Sn Plating, without PCB Locator Pegs

Connector Header Surface Mount 10 position 0.100" 2.54mm

得捷:
CONN HEADER SMD 10POS 2.54MM

贸泽:
Headers & Wire Housings C-GRID 2.54MM HDR VT SMT 2X05

艾睿:
This unshrouded 0015911102 header connector from Molex is used for jumper posts to support physical configuration options on printed circuit boards. This HDR connector&s;s 10 contacts that are made out of phosphor bronze and plated with gold over nickel. Its pitch is 2.54 mm. It has a maximum voltage rating of 250 VDC|250VAC. It has a straight body orientation. It has a header type gender. This is a 2-row connector. This device has a maximum current rating of 3 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This product is 12.7 mm long, 9.66 mm tall and 6.99 mm deep. 0015911102 is housed in black liquid crystal polymer. It uses the solder termination method. This connector has an operating temperature of -40 to 105 °C.

Verical:
Conn Unshrouded Header HDR 10 POS 2.54mm Solder ST SMD C-Grid® Tube
