2.54毫米（ .100“ ）间距KK®头，分离式，直角式表面焊接， 10电路， 0.38μm （ 15μ ”），金（Au ）选择性镀层，配合针脚长度8.23毫米（ .324 “ ） 2.54mm .100" Pitch KK® Header, Breakaway, Right Angle Surface Mount Compatible, 10 Circuits, 0.38μm 15μ" Gold Au Selective Plating, Mating Pin Length 8.23mm .324"
Connector Header Through Hole, Right Angle 10 position 0.100" 2.54mm
得捷:
CONN HEADER R/A 10POS 2.54MM
艾睿:
Use this unshrouded 0022288103 connector from Molex when board-to-board interconnects is required. This HDR connector&s;s 10 contacts that are made out of brass and plated with gold over nickel. It has a right angle body orientation. It has a maximum voltage rating of 250 V. It has a header type gender. Its pitch is 2.54 mm. This is a 1-row connector. This device has a maximum current rating of 4 A/contact. 0022288103 is housed in black nylon. It uses the solder termination method. This product is 25.4 mm long, 2.49 mm tall and 12.3 mm deep. This connector has an operating temperature of -40 to 80 °C.
