2.54毫米（ .100“ ）间距KK接头，分离式，直角式表面焊接，电路20 2.54mm .100" Pitch KK Header, Breakaway, Right Angle Surface Mount Compatible, 20 Circuits
针座 通孔，直角 20 位置 0.100"（2.54mm）
得捷:
CONN HEADER R/A 20POS 2.54MM
贸泽:
Headers & Wire Housings KK 100 Hdr Assy RA Bkwy 20 Ckt 15 SGold
艾睿:
Mounting this unshrouded 0022288203 header connector from Molex to your printed circuit board can help you support multiple physical configuration options. This HDR connector&s;s 20 contacts that are made out of brass and plated with gold over nickel. It has a header type gender. It has a maximum voltage rating of 250 V. Its pitch is 2.54 mm. This is a 1-row connector. It has a right angle body orientation. This device has a maximum current rating of 4 A/contact. It uses the solder termination method. This product is 50.8 mm long, 2.49 mm tall and 12.3 mm deep. This connector has an operating temperature of -40 to 80 °C. 0022288203 is housed in black nylon.
