3.96毫米（ .156 “ ）间距KK®头，分离式，立式，方针，带摩擦锁， 6电路 3.96mm .156" Pitch KK® Header, Breakaway, Vertical, Square Pin, with Friction Lock, 6 Circuits
针座 通孔 6 位置 0.156"（3.96mm）
得捷:
CONN HEADER VERT 6POS 3.96MM
艾睿:
Thanks to Molex&s;s unshrouded 0416710005 header connector, you can reduce the possibility of accidentally shorting out any pins on your printed circuit. This HDR connector&s;s 6 contacts that are made out of brass and plated with gold over nickel. It has a straight body orientation. It has a maximum voltage rating of 250 V. This is a 1-row connector. It has a header type gender. Its pitch is 3.96 mm. This device has a maximum current rating of 7 A/contact. This product is 23.72 mm long, 14.68 mm tall and 9.02 mm deep. It uses the solder termination method. 0416710005 is housed in black polyester. This connector has an operating temperature of -40 to 80 °C.
