集管和线壳 KK 156 Hdr Assy FrLk Bkwy 15 ckt 20 Au
Connector Header Through Hole 15 position 0.156" 3.96mm
得捷:
CONN HEADER VERT 15POS 3.96MM
艾睿:
Think of Molex&s;s wire to board 0026482155 header connector the next time you&s;re concerned about accidentally shorting out pins on your printed circuit. This HDR connector&s;s 15 contacts that are made out of brass and plated with gold over nickel. Its pitch is 3.96 mm. It has a maximum voltage rating of 250 V. This is a 1-row connector. It has a straight body orientation. It has a header type gender. This device has a maximum current rating of 7 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. 0026482155 is housed in black polyester. This connector has an operating temperature of -40 to 80 °C. It uses the solder termination method. This product is 59.39 mm long, 14.68 mm tall and 9.02 mm deep.
安富利:
Conn Wire to Board HDR 15 POS 3.96mm Solder ST Thru-Hole Bulk
