0541670208

0.50毫米（ 0.020 “ ）间距SlimStack ™插座，表面贴装，双排，垂直， 3.00and 4.00毫米（ 0.118 ”和0.157 “ ）堆叠高度，下围尺寸版本，黑色， 20Circuits 0.50mm .020" Pitch SlimStack™ Receptacle, Surface Mount, Dual Row, Vertical, 3.00and 4.00mm .118" and .157" Stacking Heights, Lower Circuit Size Version, Black, 20Circuits

20 Position Connector Receptacle, Center Strip Contacts Surface Mount Gold

得捷:
CONN RCPT 20POS SMD GOLD

立创商城:
0541670208

艾睿:
Safety is an important concern when designing electronic devices. Molex&s;s board to board 0541670208 header connector helps protect your equipment from accidental shortages. This F connector&s;s 20 contacts that are made out of brass and plated with gold over nickel. It has a maximum voltage rating of 50 VAC. It has a straight body orientation. This is a 2-row connector. Its pitch is 0.5 mm. It has a female type gender. This device has a maximum current rating of 0.5 A/contact. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. It uses the solder termination method. This product is 8.8 mm long, 2.27 mm tall and 5.4 mm deep. 0541670208 is housed in black liquid crystal polymer. This connector has an operating temperature of -40 to 105 °C.

安富利:
Conn Board to Board F 20 POS 0.5mm Solder ST SMD Embossed T/R

Verical:
Conn Board to Board RCP 20 POS 0.5mm Solder ST SMD SlimStack™ T/R
