09693017172

3 焊接杯形端接 外壳镀钢 法兰通孔 3.1 mm ### 标准DIN 41652 T 1### D-Sub 混合 - Harting

混合外壳，带预安装信号焊接杯形触点

性能级别 3

焊接杯形端接

外壳镀钢

法兰通孔 3.1 mm

### 标准

DIN 41652 T 1

### D-Sub 混合 - Harting

得捷:
CONN D-SUB RCPT 17POS SLDR CUP

欧时:
### 混合外壳，带预安装信号焊接杯形触点性能级别 3 焊接杯形端接 外壳镀钢 法兰通孔 3.1 mm ### 标准DIN 41652 T 1### D-Sub 混合 - Harting

e络盟:
连接器, 组合式D-SUB, 17W2, D Sub-M Series, DB-17W2, 插座, 17 触点, 15信号, 2电源, 焊接杯

艾睿:
This 09693017172 DVI connector from Harting will make secure connections for all of your serial ports. This female connector&s;s 15signal / 2cavity contacts that are made out of copper alloy. This connector has a single port. It has a straight body orientation. 09693017172 is housed in polyester. This device has a maximum current rating of 5 A. This product is 53 mm long, 12.5 mm tall and 14.3 mm deep. This DVI connector has an operating temperature of -55 to 125 °C. Its 15 terminals use the solder cup termination method.

Allied Electronics:
Panel Mount Hybrid Solder D-Sub Conn Socket, 15Signal, 2Power/CoaxContacts, 5A

Verical:
Conn D-Subminiature F 15Signal/2Cavity POS Solder Cup ST Panel Mount 15 Terminal 1 Port

Newark:
# HARTING  09693017172  Combination Layout D Sub Connector, D Sub-M Series, DB-17W2, Receptacle, 15 Contacts, 2, Solder
