Harting 2.54mm DIN 41652 标准 D-Sub 连接器,压印引脚,板锁一个简洁系列压印引脚 D-sub 连接器,特别适用于电缆到板应用,例如通信和数据接口连接。 这些耐用的 D 型连接器具有较长的配接寿命并且具有镍钢外壳,以及铜合金触点。标准超微型 D 连接器 模压触点 性能级别 2 金属外壳 4-40 UNC ### 标准IEC 60 807 ### Harting -(D-Sub)### Harting适合于军事应用、工业应用或者商业应用和计算机接口连接等等
Harting 2.54mm DIN 41652 标准 D-Sub ,压印引脚,板锁
一个简洁系列压印引脚 D-sub 连接器,特别适用于电缆到板应用,例如通信和数据接口连接。 这些耐用的 D 型连接器具有较长的配接寿命并且具有镍钢外壳,以及铜合金触点。
标准超微型 D 连接器
模压触点
性能级别 2
金属外壳
4-40 UNC
### 标准
IEC 60 807
### Harting
适合于军事应用、工业应用或者商业应用和计算机接口连接等等
欧时:
D 型微型 PCB 焊接连接器 25 针 M
得捷:
CONN D-SUB PLUG 25POS R/A SLDR
贸泽:
D-Sub Standard Connectors DSUB SV ML SSDP ANG73-254 25P
e络盟:
D-Sub 连接器, 直角, 标准, 插头, 25 触点, DB, 焊接
艾睿:
This 09653626813 DVI connector from Harting will make secure connections for all of your serial ports. It has a right angle body orientation. This 2-row connector has a single port. Its pitch is 2.76 mm. This device has a maximum current rating of 7.5 A. This product is 53.2 mm long, 12.4 mm tall and 12.5 mm deep. Its 25 terminals use the solder termination method. This DVI connector has an operating temperature of -55 to 125 °C.
Allied Electronics:
25 Way Right Angle Through Hole Mount PCB D-sub Connector Plug, 2.76mm Pitch
TME:
Socket; D-Sub; PIN:25; male; with threaded screw, PCB snap-in
触点数 25
极性 Male
额定电流 6.5 A
绝缘电阻 10000 MΩ
排数 2
方向 Right Angle
针脚数 25
拔插次数 250
额定电流Max 6.5 A
工作温度Max 125 ℃
工作温度Min -55 ℃
接触电阻Max 10 mΩ
安装方式 Through Hole
引脚数 25
长度 53.2 mm
宽度 12.4 mm
高度 12.4 mm
触点材质 Copper Alloy
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tray
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
09653626813 Harting Technology Group 哈丁电子 | 当前型号 | 当前型号 |
8LCM025P-301B-XX Multicomp | 功能相似 | 09653626813和8LCM025P-301B-XX的区别 |
