09676506758

09676506758图片1
09676506758图片2
09676506758概述

D-Sub标准连接器 DSUB IP67 FEM ANG PCB 50P S4 MET FRAM

In the automation industry, the Subminiature D connectors are the standard interfaces for data, signal and service / programmer interfaces. The extensive HARTING product range allows the set up of all Subminiature D interfaces common in the industry, including optional plastic and metal housings with IP 20 and IP 65 / IP 67 protection. These connectors have 9 to 50 contacts for panel mount to PCB or cable.


得捷:
CONN D-SUB RCPT 50POS R/A SLDR


贸泽:
D-Sub标准连接器 DSUB IP67 FEM ANG PCB 50P S4 MET FRAM


艾睿:
Conn D-Subminiature F 50 POS 2.54mm Solder RA Thru-Hole 50 Terminal 1 Port


Allied Electronics:
D SUB IP 67 FE ANG_PCB_50P_S4_METAL FRAM


09676506758中文资料参数规格
技术参数

触点数 50

排数 3

针脚数 50

额定电流Max 5 A

封装参数

安装方式 Through Hole

外形尺寸

高度 23.2 mm

物理参数

工作温度 -25℃ ~ 70℃

其他

产品生命周期 Active

包装方式 Bulk

符合标准

RoHS标准 RoHS Compliant

含铅标准 Lead Free

数据手册

在线购买09676506758
型号: 09676506758
制造商: Harting Technology Group 哈丁电子
描述:D-Sub标准连接器 DSUB IP67 FEM ANG PCB 50P S4 MET FRAM
