0.50毫米（ 0.020 “ ）间距FFC / FPC连接器， SMT ，直角，非ZIF ，双ContactStyle ， 1.20毫米（ 0.047 ” ）插配高度， 14电路，无铅，金（Au ）镀层 0.50mm .020" Pitch FFC/FPC Connector, SMT, Right Angle, Non-ZIF, Dual ContactStyle, 1.20mm .047" Mated Height, 14 Circuits, Lead-free, Gold Au Plating
14 Position FFC, FPC Connector Contacts, Top and Bottom 0.020" 0.50mm Surface Mount, Right Angle
得捷:
CONN FFC FPC 14POS 0.5MM R/A
艾睿:
This fpc connector 0512811494 flexible printed circuit from Molex can have discrete components built on it. Its pitch is 0.5 mm. It has a maximum voltage rating of 50 V. It has a right angle body orientation. This is a 1-row connector. This socket type connector&s;s 14 contacts that are made out of phosphor bronze and plated with gold over nickel. This device has a maximum current rating of 0.5 A/contact. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. This flexible flat cable has an operating temperature of -20 to 85 °C. This product is 9.1 mm long, 1.2 mm tall and 4.05 mm deep. It uses the solder termination method. 0512811494 is housed in natural liquid crystal polymer.
Win Source:
14 Position FFC, FPC Connector Contacts, Top and Bottom 0.020" 0.50mm Surface Mount, Right Angle
