0430450821

3.00毫米（ 0.118 “ ）间距微飞度3.0 ™接头，表面安装，双排，直角，带压入金属固定夹， 8电路 3.00mm .118" Pitch Micro-Fit 3.0™ Header, Surface Mount Compatible, Dual Row, Right Angle, with Press-fit Metal Retention Clip, 8 Circuits

针座 通孔，直角 8 位置 0.118"（3.00mm）

得捷:
CONN HEADER R/A 8POS 3MM

艾睿:
Think of Molex&s;s wire to board 0430450821 header connector the next time you&s;re concerned about accidentally shorting out pins on your printed circuit. This HDR connector&s;s 8 contacts that are made out of brass alloy and plated with tin over nickel. It has a right angle body orientation. It has a header type gender. This is a 2-row connector. Its pitch is 3 mm. It has a maximum voltage rating of 600 V. This device has a maximum current rating of 5 A/contact. The item will be shipped in tray orientation. This product is 16.15 mm long, 8.77 mm tall and 12.2 mm deep. 0430450821 is housed in black liquid crystal polymer. This connector has an operating temperature of -40 to 105 °C. It uses the solder termination method.

安富利:
Conn Wire to Board HDR 8 POS 3mm Solder RA Thru-Hole Tray

Chip1Stop:
Conn Power HDR 8 POS 3mm Solder RA Thru-Hole 8 Terminal 1 Port Micro-Fit 3.0邃｢ Tray

Verical:
Conn Header 8 POS 3mm Solder RA Thru-Hole 8 Terminal 1 Port Micro-Fit 3.0 Tray
