0430451221

3.00毫米（ 0.118 “ ）间距微飞度3.0 ™接头，表面安装，双排，直角，带压入金属固定夹，12个电路 3.00mm .118" Pitch Micro-Fit 3.0™ Header, Surface Mount Compatible, Dual Row, Right Angle, with Press-fit Metal Retention Clip, 12 Circuits

针座 通孔，直角 12 位置 0.118"（3.00mm）

得捷:
CONN HEADER R/A 12POS 3MM

艾睿:
Easily mount this wire to board 0430451221 header connector from Molex onto your PCB project to support a variety of physical configuration options. This HDR connector&s;s 12 contacts that are made out of brass alloy and plated with tin over nickel. Its pitch is 3 mm. It has a header type gender. It has a right angle body orientation. This is a 2-row connector. It has a maximum voltage rating of 600 V. This device has a maximum current rating of 5 A/contact. This component will be shipped in tray format. This product is 22.15 mm long, 8.77 mm tall and 12.2 mm deep. 0430451221 is housed in black liquid crystal polymer. It uses the solder termination method. This connector has an operating temperature of -40 to 105 °C.

安富利:
Conn Wire to Board HDR 12 POS 3mm Solder RA Thru-Hole Tray

Chip1Stop:
Conn Wire to Board HDR 12 POS 3mm Solder RA Thru-Hole Tray

Verical:
Conn Power HDR 12 POS 3mm Solder RA Thru-Hole 12 Terminal 1 Port Micro-Fit 3.0™ Tray
