BAV70 系列 80 V 200 mA 表面贴装 硅 开关二极管 - SOT-23-3
小信号开关,
Infineon 高速小信号开关二极管,电流额定值高达 1A,反向电压额定值高达 400V。 多数这些设备提供双路、三路和四路配置。
欧时:
Small signal diode,BAV70 0.2A 70V
得捷:
DIODE ARRAY GP 80V 200MA SOT23
立创商城:
80V 200mA 4ns
贸泽:
Diodes - General Purpose, Power, Switching AF DIODE 85V 0.2A
e络盟:
小信号二极管, 共阴极, 80 V, 200 mA, 1.25 V, 4 ns, 4.5 A
艾睿:
If your circuit needs to adjust from an AC to DC voltage use a switching diode BAV70E6327HTSA1 rectifier from Infineon Technologies. Its maximum power dissipation is 250 mW. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. Its peak non-repetitive surge current is 4.5 A, while its maximum continuous forward current is 0.2 A. It is made in a dual common cathode configuration. This rectifier has an operating temperature range of -65 °C to 150 °C.
Chip1Stop:
Diode Switching Si 85V 0.2A Automotive 3-Pin SOT-23 T/R
TME:
Diode: switching; SMD; 85V; 0.2A; 250mW; Package: reel, tape; SOT23
Verical:
Rectifier Diode Switching Si 85V 0.2A 4ns Automotive 3-Pin SOT-23 T/R
Newark:
# INFINEON BAV70E6327HTSA1 Small Signal Diode, Dual Isolated, 70 V, 200 mA, 1.25 V, 4 ns, 4.5 A
Win Source:
DIODE ARRAY GP 80V 200MA SOT23
额定电压DC 70.0 V
额定电流 200 mA
额定功率 250 mW
击穿电压 80.0 V
负载电流 0.2 A
针脚数 3
正向电压 1250 mV
耗散功率 250 mW
反向恢复时间 4 ns
正向电流 200 mA
最大正向浪涌电流(Ifsm) 4.5 A
正向电压Max 1.25 V
正向电流Max 200 mA
工作温度Max 150 ℃
工作温度Min -65 ℃
工作结温 150℃ Max
耗散功率Max 250 mW
安装方式 Surface Mount
引脚数 3
封装 SOT-23-3
长度 2.9 mm
宽度 1.3 mm
高度 1 mm
封装 SOT-23-3
材质 Silicon
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 车用, 电源管理, Automotive, Power Management
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
BAV70E6327HTSA1 Infineon 英飞凌 | 当前型号 | 当前型号 |
BAV70E6433HTMA1 英飞凌 | 类似代替 | BAV70E6327HTSA1和BAV70E6433HTMA1的区别 |
BAV70LT1G 安森美 | 功能相似 | BAV70E6327HTSA1和BAV70LT1G的区别 |
BAV99 飞兆/仙童 | 功能相似 | BAV70E6327HTSA1和BAV99的区别 |
