0201 3.6pF ±0.1pF 25V C0G
3.6pF ±0.1pF 25V Ceramic Capacitor C0G, NP0 0201 0603 Metric
得捷:
CAP CER 3.6PF 25V C0G/NP0 0201
艾睿:
This CL03C3R6BA3GNNC multilayer ceramic capacitor from Samsung Electro-Mechanics has so many uses that it even has a standard classification system for all its uses! It can withstand a voltage of 25 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. This product is 0.6 mm long, 0.3 mm tall and 0.3 mm deep. Its capacitance value is 3.6pF.
额定电压DC 25.0 V
电容 3.6 pF
容差 ±0.1 pF
电介质特性 C0G/NP0
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 25 V
安装方式 Surface Mount
封装公制 0603
封装 0201
长度 0.6 mm
宽度 0.3 mm
高度 0.3 mm
封装公制 0603
封装 0201
材质 C0G/-55℃~+125℃
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 10000
RoHS标准 RoHS Compliant
含铅标准 Lead Free
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
CL03C3R6BA3GNNC Samsung 三星 | 当前型号 | 当前型号 |
GJM0335C1E3R6BB01D 村田 | 类似代替 | CL03C3R6BA3GNNC和GJM0335C1E3R6BB01D的区别 |
C0603C0G1E3R6B030BG 东电化 | 功能相似 | CL03C3R6BA3GNNC和C0603C0G1E3R6B030BG的区别 |
GRM1555C1E3R6BZ01D 村田 | 功能相似 | CL03C3R6BA3GNNC和GRM1555C1E3R6BZ01D的区别 |
