双电阻器数字 NPN 晶体管,ROHM### Digital Transistors, ROHMResistor-equipped bipolar transistors, also known as Digital Transistors or Bias Resistor Transistors, incorporating one or two integrated resistors. A single series input resistor, or a potential divider of two resistors, allows these devices to be directly driven from digital sources. Both single and dual transistor versions are available.
DTD123EK Series 50 V 500 mA Surface Mount NPN Digital Transistor - SC-59
得捷:
TRANS PREBIAS NPN 200MW SMT3
立创商城:
DTD143EKT146
欧时:
双电阻器数字 NPN 晶体管,ROHM### Digital Transistors, ROHM SemiconductorResistor-equipped bipolar transistors, also known as Digital Transistors or Bias Resistor Transistors, incorporating one or two integrated resistors. A single series input resistor, or a potential divider of two resistors, allows these devices to be directly driven from digital sources. Both single and dual transistor versions are available.
e络盟:
晶体管 双极预偏置/数字, 单路NPN, 50 V, 500 mA, 4.7 kohm, 4.7 kohm
艾睿:
Trans Digital BJT NPN 50V 500mA 3-Pin SMT T/R
安富利:
Trans Digital BJT NPN 500mA 3-Pin SMT T/R
Chip1Stop:
Trans Digital BJT NPN 500mA 3-Pin SMT T/R
Verical:
Trans Digital BJT NPN 50V 500mA 3-Pin SMT T/R
Win Source:
TRANS PREBIAS NPN 200MW SMT3
DeviceMart:
TRAN DIGIT NPN 50V 500MA SOT-346
额定电压DC 50.0 V
额定电流 500 mA
额定功率 0.2 W
极性 N-Channel, NPN
耗散功率 0.2 W
击穿电压集电极-发射极 50 V
集电极最大允许电流 500mA
最小电流放大倍数hFE 47 @50mA, 5V
额定功率Max 200 mW
工作温度Max 150 ℃
工作温度Min -55 ℃
增益带宽 200 MHz
耗散功率Max 200 mW
安装方式 Surface Mount
引脚数 3
封装 SOT-23-3
长度 3 mm
宽度 1.8 mm
高度 1.2 mm
封装 SOT-23-3
工作温度 -55℃ ~ 150℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
DTD143EKT146 ROHM Semiconductor 罗姆半导体 | 当前型号 | 当前型号 |
DDTC143ECA-7-F 美台 | 功能相似 | DTD143EKT146和DDTC143ECA-7-F的区别 |
DDTD143EC-7-F 美台 | 功能相似 | DTD143EKT146和DDTD143EC-7-F的区别 |
DTD143EK 罗姆半导体 | 功能相似 | DTD143EKT146和DTD143EK的区别 |
