ESD 抑制器/TVS 二极管 26V Uni-Directional 28Vbr 9.5A 100nA
Are you a designer worried about electrostatic discharge? Do not risk it, add this tvs ESD protection device from Zetex. This ESD diode has a maximum ESD protection device voltage of ±30@Air Gap/±30@Contact Disc kV. This device"s maximum clamping voltage is 40 V. This ESD diode has an operating temperature range of -65 °C to 150 °C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. Its capacitance value is 630Typ pF. It is made in a single configuration.
额定功率 300 W
击穿电压 28 V
耗散功率 0.5 W
钳位电压 40 V
脉冲峰值功率 300 W
最小反向击穿电压 28 V
工作温度Max 150 ℃
工作温度Min -65 ℃
耗散功率Max 500 mW
安装方式 Surface Mount
引脚数 2
封装 UDFN-2
长度 2 mm
宽度 2 mm
高度 0.575 mm
封装 UDFN-2
工作温度 -65℃ ~ 150℃
产品生命周期 Unknown
包装方式 Tape & Reel TR
制造应用 通用
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
