FTS-106-02-L-DV

SAMTEC FTS-106-02-L-DV Board-To-Board Connector, 1.27mm, 12Contacts, Header, FTS Series, Surface Mount, 2Rows

针座 表面贴装型 12 位置 0.050"（1.27mm）

得捷:
CONN HEADER SMD 12POS 1.27MM

艾睿:
Reduce safety concerns with this unshrouded FTS-106-02-L-DV header connector from Samtec which will reduce the possibility of accidentally shorting pins when a printed circuit board is being used. This HDR connector&s;s 12 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a straight body orientation. This is a 2-row connector. Its pitch is 1.27 mm. It has a header type gender. This device has a maximum current rating of 1.75 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This connector has an operating temperature of -55 to 125 °C. FTS-106-02-L-DV is housed in black liquid crystal polymer. It uses the solder termination method. This product is 7.62 mm long, 3.18 mm tall and 5.84 mm deep.

安富利:
Conn Unshrouded Header HDR 12 POS 1.27mm Solder ST SMD Tube

Newark:
# SAMTEC  FTS-106-02-L-DV  Board-To-Board Connector, 1.27 mm, 12 Contacts, Header, FTS Series, Surface Mount, 2 Rows
