LM25574MTX/NOPB

TEXAS INSTRUMENTS  LM25574MTX/NOPB  直流-直流开关降压逐步递减稳压器, 可调, 6V-42V输入, 1.225V-40V输出, 500mA输出, TSSOP-16

The is a SIMPLE SWITCHER® easy-to-use Buck Regulator which allows design engineers to design and optimize a robust power supply using a minimum set of components. Operating with an input voltage range of 6 to 42V, the LM25574 delivers 0.5A of continuous output current with an integrated 750mR N-channel MOSFET. The regulator utilizes an emulated current mode architecture which provides inherent line regulation, tight load transient response and ease of loop compensation without the usual limitation of low-duty cycles associated with current mode regulators. The operating frequency is adjustable from 50kHz to 1MHz to allow optimization of size and efficiency. To reduce EMI, a frequency synchronization pin allows multiple IC"s from the LM2557x family to self-synchronize or to synchronize to an external clock. The LM25574 guarantees robustness with cycle-by-cycle current limit, short-circuit protection, thermal shut-down and remote shut-down.

.

Master or slave frequency synchronization

.

Adjustable soft-start

.

Emulated current mode control architecture

.

Wide bandwidth error amplifier

.

Built-in protection

.

Integrated 42V, 750mR N-channel MOSFET

.

1.5% Feedback reference accuracy

.

Green product and no Sb/Br
