LT6200CS8-10#PBF

LINEAR TECHNOLOGY  LT6200CS8-10#PBF  运算放大器, 单路, 1.6 GHz, 1个放大器, 450 V/µs, 2.5V 至 12.6V, SOIC, 8 引脚

The is a single ultralow noise rail-to-rail input and output unity gain stable Operational Amplifier that feature 0.95nV/√Hz noise voltage. The amplifier combine very low noise with a 165MHz gain bandwidth, 50V/µs slew rate and optimized for low voltage signal conditioning systems. A shutdown pin reduces supply current during standby conditions and thermal shutdown protects the part from overload conditions. The LT6200 family maintains its performance for supplies from 2.5 to 12.6V and is specified at 3, 5 and ±5V. The amplifier can be used as plug-in replacements for many high speed op amps to improve input/output range and noise performance.

.

Input common mode range includes both rails

.

Output swings rail-to-rail

.

1mV Maximum low offset voltage

.

60mA Minimum output current

.

Power shutdown, thermal shutdown
