40W to 60W Medically Approved, Single/Triple Output
In-built EMI filter Class B
Overload and overvoltage protection
Medical safety approvals
Remote sense on main output
Adjustable output option
Frequency | 47-440Hz
---|---
Connections | Molex KK not supplied
Forced air cooling of 30CFM @ 50°C increases the 40W O/P to 55W, and the 60W units to 80W. Ratings are reduced with a cover kit. |
### 注
Total of output loads must not exceed rating of unit. Figures in brackets indicate overall size with cover.
### 标准
VDE0750/EN60601-1, UL2901, CSA 22.2 NO 601.1
额定功率 40 W
输出接口数 3
输出电压 5.00 V, 12.0 V, -12.0 V
输出功率 40 W
输入电压DC Max 300 V
输入电压DC Min 120 V
输入电压AC Max 264 V
输入电压AC Min 85 V
输入电流Min 1 Arms
额定功率Max 40 W
工作温度Max 50 ℃
工作温度Min 0 ℃
输入电压 85VAC ~ 264VAC
安装方式 Chassis
引脚数 10
封装 开放式
长度 127 mm
宽度 76.2 mm
高度 28.956 mm
封装 开放式
重量 230 g
工作温度 0℃ ~ 70℃
产品生命周期 Active
包装方式 Bulk
制造应用 医用型
RoHS标准 RoHS Compliant
含铅标准 Lead Free
