LP3872ES-2.5/NOPB

LDO（低压降）线性稳压器，1.5A，LP38xx/LP39xx系列，Texas Instruments### LDO（低压降）线性稳压器，Texas Instruments低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。

LDO（低压降）线性稳压器，1.5A，LP38xx/LP39xx系列，Texas Instruments

### LDO（低压降）线性稳压器，Texas Instruments

低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。

得捷:
IC REG LINEAR 2.5V 1.5A DDPAK

立创商城:
LP3872ES-2.5/NOPB

德州仪器TI:
1.5-A, low-dropout voltage regulator with power good & enable

欧时:
Texas Instruments LP3872ES-2.5/NOPB LDO 稳压器, 2.5 V输出, 1.5A最大输出, ±1.5%精确度

贸泽:
LDO Voltage Regulators 1.5A Low Dropout LDO

艾睿:
Don&s;t let unpredictable voltage levels ruin your circuit! Use this LDO LP3872ES-2.5/NOPB linear regulator from Texas Instruments to control your voltage levels! It has an overall accuracy of ±1.5 %. Its typical dropout voltage at current is 0.038@150mA|0.38@1.5A V. This voltage regulation device&s;s single output can produce a current up to 1.5 A. It only needs a voltage of at least 2.5 V while not exceeding 7 V to effectively power your circuit. With a fixed output that has a voltage of 2.5 V, this is power management at its best. Maintain a constant voltage level with a load regulation of 0.06%Typ and line regulation of 0.02%Typ. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C. Its polarity is positive. The maximum dropout voltage is 0.05@150mA|0.45@1.5A V.

安富利:
LDO Regulator Pos 2.5V 1.5A 6-Pin5+Tab TO-263 Rail

Verical:
LDO Regulator Pos 2.5V 1.5A 6-Pin5+Tab TO-263 Tube

DeviceMart:
IC REG LDO 2.5V 1.5A TO-263-5

Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 2.5V 1.5A DDPAK/TO-263-5
