LDO(低压降)线性稳压器,1.5A,LP38xx/LP39xx系列,Texas Instruments### LDO(低压降)线性电压调节器,Texas Instruments低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。
LDO(低压降)线性稳压器,1.5A,LP38xx/LP39xx系列,Texas Instruments
### LDO(低压降)线性稳压器,Texas Instruments
低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。
得捷:
IC REG LIN POS ADJ 1.5A SOT223-5
立创商城:
LP3852EMP-2.5/NOPB
德州仪器TI:
1.5-A, 7-V, ultra-low-dropout voltage regulator with power good & enable
欧时:
Texas Instruments LP3852EMP-2.5/NOPB LDO 稳压器, 2.5 V输出, 1.5A最大输出, ±1.5%精确度
贸泽:
低压差稳压器 1.5A Fast Response Ultra Low Dropout Linear Regulators 5-SOT-223 -40 to 125
艾睿:
Keep calm and stay stable by implementing this LDO LP3852EMP-2.5/NOPB linear regulator developed by Texas Instruments. Its typical dropout voltage at current is 0.026@150mA|0.26@1.5A V. It has an overall accuracy of ±1.5 %. This voltage regulation device&s;s single output can produce a current up to 1.5 A. Supply your circuit with sufficient power by implementing this, which requires a minimum input voltage of 2.5 V that does not exceed 7 V. With a fixed output that has a voltage of 2.5 V, this is power management at its best. Using a load regulation of 0.06%Typ and line regulation of 0.02%Typ is needed for a programmable DC power supply. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. The maximum dropout voltage is 0.035@150mA|0.32@1.5A V. Its polarity is positive. This voltage regulation device has an operating temperature range of -40 °C to 125 °C.
安富利:
LDO Regulator Pos 2.5V 1.5A 5-Pin4+Tab SOT-223 T/R
Chip1Stop:
LDO Regulator Pos 2.5V 1.5A 5-Pin4+Tab SOT-223 T/R
Verical:
LDO Regulator Pos 2.5V 1.5A 5-Pin4+Tab SOT-223 T/R
Newark:
# TEXAS INSTRUMENTS LP3852EMP-2.5/NOPB Fixed LDO Voltage Regulator, 2.5V to 7V, 240mV Dropout, 2.5Vout, 1.5Aout, SOT-223-5
DeviceMart:
IC REG LDO 2.5V 1.5A SOT223-5
Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 2.5V 1.5A SOT-223-5
容差 ±3 %
输出接口数 1
输出电压 2.5 V
输出电流 1.5 A
供电电流 3mA ~ 10mA
静态电流 4 mA
输出电容类型 Ceramic
跌落电压 240 mV
调节输出数 1
输入电压Max 7 V
输入电压Min 2.5 V
输出电压Min 2.5 V
输出电流Max 1.5 A
工作温度Max 125 ℃
工作温度Min -40 ℃
精度 ±1.5 %
输入电压 ≤7 V
安装方式 Surface Mount
引脚数 5
封装 TO-261-5
长度 6.5 mm
宽度 3.56 mm
高度 1.6 mm
封装 TO-261-5
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LP3852EMP-2.5/NOPB TI 德州仪器 | 当前型号 | 当前型号 |
LP3852EMPX-2.5 德州仪器 | 完全替代 | LP3852EMP-2.5/NOPB和LP3852EMPX-2.5的区别 |
LP3852EMP-2.5 德州仪器 | 类似代替 | LP3852EMP-2.5/NOPB和LP3852EMP-2.5的区别 |
LP3852EMPX-2.5/NOPB 德州仪器 | 类似代替 | LP3852EMP-2.5/NOPB和LP3852EMPX-2.5/NOPB的区别 |
