Step-Down DC/DC Converters Integrated Switch up to 6V Input Max., LM Series, Texas Instruments### 直流/直流开关调节器转换器(集成开关),Texas InstrumentsTexas Instruments 的此系列高度集成的高效开关稳压器包括步升(升压)、步降(降压)、步升/降(增压/降压)和反相类型,为每个直流稳压器应用提供高效的解决方案。
Step-Down DC/DC Converters Integrated Switch up to 6V Input Max., LM Series, Texas Instruments
### 直流/直流开关调节器转换器(集成开关),Texas Instruments
Texas Instruments 的此系列高度集成的高效开关稳压器包括步升(升压)、步降(降压)、步升/降(增压/降压)和反相类型,为每个直流稳压器应用提供高效的解决方案。
得捷:
IC REG BUCK ADJ 5A 16HTSSOP
立创商城:
降压型 Vin=2.95V~5.5V Vout=800mV~4.68V 5A
德州仪器TI:
2.95-5.5V, 5A, Current Mode Synchronous Buck Regulator with Adjustable Frequency
欧时:
### Step-Down DC/DC Converters Integrated Switch up to 6V Input Max., LM Series, Texas Instruments### 直流/直流开关调节器转换器(集成开关),Texas InstrumentsTexas Instruments 的此系列高度集成的高效开关稳压器包括步升(升压)、步降(降压)、步升/降(增压/降压)和反相类型,为每个直流稳压器应用提供高效的解决方案。
艾睿:
Adjust the voltage level of your devices with this step down LM20145MH/NOPB DC to DC converter from Texas Instruments. This converter&s;s single output can produce a current up to 5 A. It only needs a voltage of at least 2.95 V while not exceeding 5.5 V to effectively power your circuit. With an adjustable output that has a voltage of 0.8 to 5 V, this is power management at its best. This converter is 97 % efficient. Users like the load regulation of 0.08%/ATyp. You can operate this at a switching frequency of 260 to 750 kHz. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This converter has a minimum operating temperature of -40 °C and a maximum of 125 °C.
安富利:
Conv DC-DC Single Step Down 2.95V to 5.5V 16-Pin TSSOP EP Rail
Chip1Stop:
Conv DC-DC Single Step Down 2.95V to 5.5V 16-Pin TSSOP EP Rail
Verical:
Conv DC-DC 2.95V to 5.5V Step Down Single-Out 0.8V to 5V 5A 16-Pin HTSSOP EP Tube
Newark:
# TEXAS INSTRUMENTS LM20145MH/NOPB DC-DC Switching Step Down Regulator, Adjustable, 2.95V-5.5Vin, 0.8V-5Vout, 5Aout, TSSOP-16
DeviceMart:
IC REG BUCK SYNC ADJ 5A 16TSSOP
输出接口数 1
输出电压 0.8V ~ 5V
输出电流 5 A
静态电流 3.50 mA
调节输出数 1
开关频率 260kHz ~ 750kHz
拓扑结构 Buck
输入电压Max 5.5 V
输入电压Min 2.95 V
输出电压Max 4.68 V
输出电压Min 0.8 V
输出电流Max 5 A
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压 2.95 V
输入电压 2.95V ~ 5.5V
安装方式 Surface Mount
引脚数 16
封装 TSSOP-16
长度 5 mm
宽度 4.4 mm
高度 0.9 mm
封装 TSSOP-16
工作温度 -40℃ ~ 125℃ TJ
产品生命周期 Active
包装方式 Cut Tape CT
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LM20145MH/NOPB TI 德州仪器 | 当前型号 | 当前型号 |
LM20145MHE/NOPB 德州仪器 | 完全替代 | LM20145MH/NOPB和LM20145MHE/NOPB的区别 |
LM20145MHX/NOPB 德州仪器 | 类似代替 | LM20145MH/NOPB和LM20145MHX/NOPB的区别 |
