LQW18AN56NJ00D

Murata 0603 LQW18AN 系列线绕电感器高质量线圈电感器，设计用于 VHF 和 UHF 应用。 高谐振频率。 低容差电感值。 带有后缀 "10D" 的型号具有较低直流电阻值。 **应用：**高频率电路，用于无线电信设备：例如蓝牙、GSM、W-LAN。

固定器

欧时:
### Murata 0603 LQW18AN 系列线绕电感器高质量线圈电感器，设计用于 VHF 和 UHF 应用。 高谐振频率。 低容差电感值。 带有后缀 "10D" 的型号具有较低直流电阻值。 **应用：**高频率电路，用于无线电信设备：例如蓝牙、GSM、W-LAN。 ![http://china.rs-online.com/largeimages/L0109217-10.jpg]http://china.rs-online.com/largeimages/L0109217-10.jpg ### SMT 0603 电感器（扼流圈）

立创商城:
56nH ±5% 350mΩ

得捷:
FIXED IND 56NH 360MA 350MOHM SMD

艾睿:
Is space on a PCB a limiting factor for your electronic circuit design? Then use this rf chip LQW18AN56NJ00D surface mount inductor from Murata to save valuable space. This SMD inductor has a minimum operating temperature of -55 °C and a maximum of 125 °C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. This SMD inductor has a maximum DC current of 360m A with a maximum resistance of 350m Ohm. This product is 1.8 mm long, 1 mm tall and 1 mm deep. It has a tolerance of 5%. Its test frequency is 100M Hz, while its minimum self-resonant frequency is 2.4G Hz. This device is made with wirewound technology. It has an inductance of 56n H.

安富利:
Ind RF Chip Wirewound 56nH 5% 100MHz 38Q-Factor 360mA 0603 Paper T/R

Chip1Stop:
Inductor RF Chip Wirewound 56nH 5% 100MHz 38Q-Factor 360mA 350mOhm DCR 0603 T/R

TME:
Inductor: wire; SMD; 0603; 56nH; 360mA; 0.35Ω; ftest:100MHz; Q:38

Verical:
Inductor RF Chip Unshielded Wirewound 0.056uH 5% 100MHz 38Q-Factor Non Magnetic 0.36A 0.35Ohm DCR 0603 T/R

儒卓力:
**LQW18AN 0,056uH 360mA 5% WWT **

Win Source:
56nH Unshielded Wirewound Inductor 360mA 350 mOhm Max 0603 1608 Metric
