MAXIM INTEGRATED PRODUCTS MAX4601CAE+ 模拟开关, CMOS, SPST - 常闭, 4 放大器, 4 ohm, 4.5V 至 36V, ± 4.5V 至 ± 20V, SSOP, 16 引脚
The is a quad SPST CMOS analogue switch in 16 pin SSOP package. This device can handle rail to rail analogue signals and off leakage current is 2.5nA maximum at TA = +85°C. The MAX4601 is ideal in low distortion applications and is preferred solution over mechanical relays in automatic test equipment or applications where current switching is required. It has low power requirements and requires less board space. This analogue switch is more reliable than mechanical relays. All digital inputs have +0.8V and +2.4V logic thresholds, ensuring TTL/CMOS logic compatibility when using ±15V or single +12V supply. It is used in PBX systems, PABX systems and audio signal routing.
电路数 4
通道数 4
针脚数 16
耗散功率 571 mW
工作温度Max 70 ℃
工作温度Min 0 ℃
耗散功率Max 571 mW
电源电压Max 36 V
电源电压Min 4.5 V
安装方式 Surface Mount
引脚数 16
封装 SSOP-16
长度 6.33 mm
宽度 5.38 mm
高度 1.78 mm
封装 SSOP-16
工作温度 0℃ ~ 70℃
产品生命周期 Unknown
包装方式 Tube
制造应用 Signal Processing, Avionics, Communications & Networking
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MAX4601CAE+ Maxim Integrated 美信 | 当前型号 | 当前型号 |
MAX4601CAE+T 美信 | 完全替代 | MAX4601CAE+和MAX4601CAE+T的区别 |
MAX4601CAE 美信 | 完全替代 | MAX4601CAE+和MAX4601CAE的区别 |
MAX4601EAE+ 美信 | 类似代替 | MAX4601CAE+和MAX4601EAE+的区别 |
