Microchip### 比较器,Microchip
单,
### 比较器,Microchip
得捷:
IC COMPARATOR 1 GEN PUR SOT23-5
立创商城:
MCP6541RT-I/OT
欧时:
Microchip MCP6541RT-I/OT 比较器, 推挽式输出, 0.85μs, 多种电源电压适用, 5引脚 SOT-23封装
e络盟:
模拟比较器, 亚微安, 1个比较器, 1.6V 至 5.5V, SOT-23, 5 引脚
艾睿:
Don&s;t forget to compare the input voltages and currents in your electronics device with this MCP6541RT-I/OT comparator circuit from Microchip Technology. It has a push-pull output. This comparator has a minimum operating temperature of -40 °C and a maximum of 85 °C. This device is made with CMOS technology. This device uses a single power supply. It has a single channel per chip. Its typical PSRR is 80 dB.
Allied Electronics:
Single 1.6V Push/Pull Comparator, I temp; rvs pinout5 SOT-23T/R
Chip1Stop:
Comparator Single R-R I/O 5.5V Automotive 5-Pin SOT-23 T/R
Verical:
Comparator Single R-R I/O 5.5V Automotive 5-Pin SOT-23 T/R
儒卓力:
**1xComp 4µs SOT23-5 SMD **
Win Source:
IC COMP 1.6V PUSH-PULL SOT23-5
电源电压DC 1.60V min
输出电流 2.00 mA
电路数 1
通道数 1
针脚数 5
共模抑制比 70 dB
热阻 256 ℃/W
输入补偿电压 7 mV
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 1.6V ~ 5.5V
安装方式 Surface Mount
引脚数 5
封装 SOT-23-5
长度 3.1 mm
宽度 1.8 mm
高度 1.3 mm
封装 SOT-23-5
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MCP6541RT-I/OT Microchip 微芯 | 当前型号 | 当前型号 |
MCP6541T-I/OT 微芯 | 完全替代 | MCP6541RT-I/OT和MCP6541T-I/OT的区别 |
MCP6541RT-E/OT 微芯 | 类似代替 | MCP6541RT-I/OT和MCP6541RT-E/OT的区别 |
MCP6541T-E/OT 微芯 | 类似代替 | MCP6541RT-I/OT和MCP6541T-E/OT的区别 |
