ME60A2403F01

ME60A 替代 MENB1060 60 W 24 V Level VI 输入 插座 桌面 适配器

A high performance AC to DC external power supply family designed for medical applications. The ME60A Medical Series low

power external AC-DC power supplies are approved to safety EN/IEC/UL60601-1, 3rd edition and EN/IEC/UL60601-1-11:2010

for Home Healthcare non-hospital use applications with and isolation levels which satisfy the 2 MOPP requirements and

designed to UL/EN/IEC60601-1-2, 4th edition for EMC

.

. The ME60A Series models will operate at universal input range of 90 to

264Vac over the wide temperature range of -20°C to +50°C, delivering full rated output power up to +40°C and applicable

output power derating at 50°C. These models are available in desktop versions, include an IP22 rating per IEC60529 for the

enclosure, and the output cable can be terminated at a variety of output connectorsMeets UL/EN/IEC60601-1-2, 4th edition for

EMC

.

Approved to EN/IEC/UL60601-1, 3rd edition

with isolation levels which satisfy the 2 MOPP

requirements

Meets DoE Efficiency Level VI Requirements

No load input power

Average Efficiency

Up to 60W of AC-DC Power

Universal Input 90-264Vac Input Range

Desktop Style Package

Meets EN55011/CISPR11, FCC Part 15.109

Class B Conducted & Radiated Emissions, with

6db margin

E-cap life of >7 years

3 Year Warranty

IP22 Rated Enclosure
