模数转换器 - ADC +2.7V, Low-Power, Multichannel, Serial, 8-Bit ADCs
8 位模数转换器 2,4 输入 1 SAR 16-QSOP
得捷:
IC ADC 8BIT SAR 16QSOP
贸泽:
模数转换器 - ADC +2.7V, Low-Power, Multichannel, Serial, 8-Bit ADCs
安富利:
The MAX1110/MAX1111 low-power, 8-bit, 8-channel analog-to-digital converters ADCs feature an internal track/hold, voltage reference, clock, and serial interface. They operate from a single 2.7V to 5.5V supply and consume only 85µA while sampling at rates up to 50ksps. The MAX1110"s 8 analog inputs and the MAX1111"s 4 analog inputs are software-configurable, allowing unipolar/bipolar and single-ended/differential operation.Successive-approximation conversions are performed using either the internal clock or an external serial-interface clock. The full-scale analog input range is determined by the 2.048V internal reference, or by an externally applied reference ranging from 1V to VDD. The 4-wire serial interface is compatible with the SPI™, QSPI™, and MICROWIRE™ serial-interface standards. A serial-strobe output provides the end-of-conversion signal for interrupt-driven processors.The MAX1110/MAX1111 have a software-programmable, 2µA automatic power-down mode to minimize power consumption. Using power-down, the supply current is reduced to 6µA at 1ksps, and only 52µA at 10ksps. Power-down can also be controlled using the active-low SHDN input pin. Accessing the serial interface automatically powers up the device.The MAX1110 is available in a 20-pin SSOP package. The MAX1111 is available in a small 16-pin QSOP package.
Win Source:
IC ADC 8BIT LP 16-QSOP
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MAX1111CEE+T Maxim Integrated 美信 | 当前型号 | 当前型号 |
MAX1111EEE/V+T 美信 | 完全替代 | MAX1111CEE+T和MAX1111EEE/V+T的区别 |
MAX1111CEE+ 美信 | 类似代替 | MAX1111CEE+T和MAX1111CEE+的区别 |
MAX1111EEE+ 美信 | 类似代替 | MAX1111CEE+T和MAX1111EEE+的区别 |
