120 W 单输出 10 A 12 Vdc 输出 最大值 墙插式端接 LED 驱动器
12V 120 W AC/DC 外部 台式(类 II) 适配器 软线 输入
得捷:
AC/DC DESKTOP ADAPTER 12V 120W
艾睿:
Use electrical sub-system energy to power your electronic devices using a regulated OWA-120U-12 portable external plug-in adapter from Mean-Well USA, Inc.. This part&s;s single output can handle a current up to 10 A. This part has an input voltage of 90 to 264 V. It has a fixed output that has a voltage of 12 V and maximum output power of 120 W. This part has a minimum operating temperature of -40 °C and a maximum of 70 °C.
Jameco:
120W 10A 12V Single Output Waterproof Switching Adaptor
安富利:
AC/DC Power Supply Single-OUT 12V 10A 120W
富昌:
120 W 单输出 10 A 12 Vdc 输出 最大值 墙插式端接 LED 驱动器
TME:
Pwr sup.unit: switched-mode; for LED diodes; 120W; 12VDC; 10A
MASTER:
AC/DC Adapter - Desktop - 120 Watts: 12V @ 10A - NA Input Blades
Electro Sonic:
AC/DC Adapter - Desktop - 120 Watts: 12V @ 10A - NA Input Blades
CDI:
LED Driver CC 120W 10000mA Linear 7.2-12Vdc 90-264Vac PFC Non-Dimming IP67 LED Adapter Desktop
额定功率 120 W
输出接口数 1
输出电压 12 V
输出电流 10 A
输出功率 120 W
额定电流Max 1.3 A
输入电流Min 1.3 A
输出功率Max 120 W
工作温度Max 70 ℃
工作温度Min -40 ℃
电源电压 90.264VAC, 127.370VDC
封装 LED Adapter Desktop
封装 LED Adapter Desktop
重量 1115 g
工作温度 -40℃ ~ 70℃
产品生命周期 Active
包装方式 Bulk
制造应用 ITE(商业)
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
