PE-0805CM331JTT

0805 330nH ±5% 300mA

330nH Unshielded Wirewound Inductor 300mA 1.28Ohm Max 0805 2012 Metric

得捷:
FIXED IND 330NH 300MA 1.28 OHM

贸泽:
Fixed Inductors SMD IND

艾睿:
An ideal space-saving electronic component is this rf chip PE-0805CM331JTT surface mount inductor from Pulse. This SMD inductor has an operating temperature range of -40 °C to 125 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. It has a tolerance of 5%. This device utilizes wirewound technology. Its test frequency is 100M Hz, while its minimum self-resonant frequency is 775M Hz. It has an inductance of 330n H. This product is 2.29 mm long, 1.58 mm tall and 1.68 mm deep. This SMD inductor has a maximum DC current of 300m A with a maximum resistance of 1.28 Ohm.

Chip1Stop:
Inductor RF Chip Wirewound 330nH 5% 100MHz 40Q-Factor Ceramic 300mA 1.28Ohm DCR 0805 T/R

Verical:
Inductor RF Chip Wirewound 0.33uH 5% 100MHz 40Q-Factor Ceramic 0.3A 1.28Ohm DCR 0805 T/R
