PCF1A560MCL4GB

Cap Aluminum Polymer 56uF 10VDC 20% 6.3 X 5.5mm SMD 0.025Ω 2500mA 2000H 105℃ Automotive T/R

This conductive polymer aluminum solid capacitor from is able to support a change in the load in an integrated circuit. It can withstand a voltage of 10 VDC. It has 2 terminals. This product is 5.5 mm tall with a diameter of 6.3 mm. This conductive polymer aluminum solid capacitor has an operating temperature range of -55 °C to 105 °C. It has a tolerance of 20%. Its leakage current is 112@2Min μA.
