QorIQ, 32Bit Power Arch, SoC, 800MHz, USB, SATA, SEC, GbE, PCIe, DDR3, -40C to 105C, Rev2.01
Overview
The QorIQ® P1010 and P1014 communications processors expand QorIQ performance into cost- and power-sensitive applications. Based on 45 nm technology, the processors provide performance up to 1000 MHz and power dissipation as low as 1.1 watts, along with extensive integration and a rich set of interfaces that target cost-sensitive endpoint applications such as:
* IP Camera
* Industrial Robot
* Wireless LAN WLAN Access Point
* Network Attached Storage
* Printing and Imaging
* Router
MoreLess
## Features
### CORE COMPLEX
* Single e500 core, built on Power Architecture® technology
* 32 KB of L1 instruction cache and 32 KB of L1 data cache
* 400 to 1000 MHz core clock frequency
* 256 KB L2 cache with ECC, also configurable as SRAM and stashing memory
### NETWORKING ELEMENTS
* SerDes
* 6 lanes at up to 3.125 GHz
* Supports SGMII, PCI Express® PCIe and SATA
### ACCELERATORS AND MEMORY CONTROL
* 16-/32-bit DDR3 SDRAM memory controller with ECC support
* Hardware based cryptography acceleration SEC4.0
* Up to three gigabit Ethernet interfaces with support for IEEE® 1588
* TCP/IP acceleration, quality of service and classification capabilities
* Support for RGMII and SGMII
### BASIC PERIPHERALS AND INTERCONNECT
* 1 x USB controller USB 2.0 with integrated PHY, OTG and device support
* 2x Serial ATA SATA2.0 controllers
* Serial peripheral interface SPI
* Trusted boot platform, integrated security
* Four-channel DMA controller
* 2 x I²C controllers, 2 x DUARTs, timers
* Integrated flash controller IFC with enhanced capabilities to support large pages
* 2x PCIe controllers
* 2x FlexCAN interfaces to support industrial protocols
### ADDITIONAL FEATURES
* Trusted boot platformComparison Table
| P1010 | P1014
\---|---|---
**Core Frequency** | 533 to 1000 MHz | 400 to 800 MHz
**L2 Cache** | 256 KB | 256 KB
**DDR3** | 16/32-bit @ 800 MHz | 16-bit @ 800 MHz
**GE Ports** | 3 | 2
**SATA** | 2 | 2
**PCI Express** | 2 | 2
**Security** | Trusted | No
**CAN** | 2 | No
