SMAZ27-TP

MICRO COMMERCIAL COMPONENTS  SMAZ27-TP  齐纳二极管, 1W, 27V, DO-214AC

Features

• 1.0W Power Dissipation

• High Surge Capability

• Ideally Suited for Automatic Assembly

• Standard VZ Tolerance is +/- 5%

• Lead Free Finish/Rohs Compliant Note1 "P"Suffix designates Compliant. See ordering information

• Epoxy meets UL 94 V-0 flammability rating

• Moisture Sensitivity Level 1

• Halogen free available upon request by adding suffix "-HF"

得捷:
DIODE ZENER 27V 1W DO214AC

贸泽:
稳压二极管 25mA, 27V

e络盟:
齐纳二极管, 1W, 27V, DO-214AC

艾睿:
This SMAZ27-TP zener diode from Micro Commercial Components is perfect for blocking a voltage. Its maximum power dissipation is 1000@Ta=50C mW. This device has a maximum regulator current of 37 mA. Its maximum leakage current is 0.5 μA. Its test current is 25 mA. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. This zener device has a nominal voltage of 27 V and a voltage tolerance of 5%. This zener diode has a minimum operating temperature of -65 °C and a maximum of 150 °C. It is made in a single configuration.

Chip1Stop:
Diode Zener Single 27V 5% 1W 2-Pin SMA T/R

Newark:
# MICRO COMMERCIAL COMPONENTS  SMAZ27-TP  Zener Single Diode, 27 V, 1 W, DO-214AC, 5 %, 2 Pins, 150 °C
