74BCT 系列,Texas InstrumentsBiCMOS TTL 逻辑 工作电压:4.5 至 5.5 兼容性:输入 LVTTL/TTL、输出 TTL ### 74BCT 系列
74BCT 系列,Texas Instruments
BiCMOS TTL 逻辑
工作电压:4.5 至 5.5
兼容性:输入 LVTTL/TTL、输出 TTL
得捷:
IC SCAN TEST DEVICE BUFF 24-SOIC
立创商城:
SN74BCT8240ADW
欧时:
### 74BCT 系列,Texas InstrumentsBiCMOS TTL 逻辑 工作电压:4.5 至 5.5 兼容性:输入 LVTTL/TTL、输出 TTL ### 74BCT 系列
贸泽:
Specialty Function Logic Device w/Octal Inverting Buffers
艾睿:
Amplify analog and digital signals by driving the input to the transmission line with this SN74BCT8240ADW buffer and line driver from Texas Instruments. With a 3-state output, this is power management at its best. This line driver has a minimum operating temperature of 0 °C and a maximum of 70 °C. This device comes in tube packaging. It has 8 channels per chip. This inverting device has a typical operating supply voltage of 5 V. Its minimum operating supply voltage of 4.5 V, while its maximum is 5.5 V.
安富利:
Scan Buffer/Line Driver 8-CH Inverting 3-ST BiCMOS 24-Pin SOIC Tube
Chip1Stop:
Scan Buffer/Line Driver 8-CH Inverting 3-ST BiCMOS 24-Pin SOIC Tube
Verical:
Scan Buffer/Line Driver 8-CH Inverting 3-ST BiCMOS 24-Pin SOIC Tube
DeviceMart:
IC SCAN TEST DEVICE BUFF 24-SOIC
电源电压DC 4.50V ~ 5.50V
输出接口数 8
通道数 8
位数 8
传送延迟时间 9.00 ns
电压波节 5.00 V
输出电流驱动 -234 µA
输入数 8
工作温度Max 70 ℃
工作温度Min 0 ℃
耗散功率Max 1700 mW
电源电压 4.5V ~ 5.5V
安装方式 Surface Mount
引脚数 24
封装 SOIC-24
长度 15.6 mm
宽度 7.6 mm
高度 2.35 mm
封装 SOIC-24
工作温度 0℃ ~ 70℃
产品生命周期 Active
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SN74BCT8240ADW TI 德州仪器 | 当前型号 | 当前型号 |
SN74BCT8240ADWR 德州仪器 | 完全替代 | SN74BCT8240ADW和SN74BCT8240ADWR的区别 |
SN74BCT8240ADWRG4 德州仪器 | 完全替代 | SN74BCT8240ADW和SN74BCT8240ADWRG4的区别 |
5962-9174601QLA 德州仪器 | 完全替代 | SN74BCT8240ADW和5962-9174601QLA的区别 |
