红外发射器, 880 nm, 15 °, T-1 3mm, 700 ns, 700 ns
红外(IR) 发射器 880nm 1.7V 50mA 1.4mW/cm² @ 20mA 15° 径向
得捷:
EMITTER IR 880NM 50MA RADIAL
欧时:
Honeywell SEP8705 系列 IRED Honeywell 的 SEP8705 系列是红外线 IR 发光二极管,采用标准 T-1 3mm 封装。 它们具有模制灰色塑料封装,提供高功率密度。 SEP8705 系列的特点: 标准 T-1 3mm 封装 卓越的光学中心线性能 红外线 IR 发射器,Honeywell
e络盟:
红外发射器, 880 nm, 15 °, T-1 3mm, 700 ns, 700 ns
艾睿:
Infrared Emitter 880nm Circular Top Mount 2-Pin T-1
Allied Electronics:
Diode; Infrared Emitter; T-1; 880 nm; 1.7 V; 50 mA; -40 degC; 85 degC; 70 mW;
Chip1Stop:
Infrared Emitter 880nm Circular Top Mount 2-Pin T-1
Verical:
Infrared Emitter 880nm Circular Top Mount 2-Pin T-1
Newark:
# HONEYWELL SEP8705-002 Infrared Emitter, 15 °, T-1 3mm, 50 mA, 1.7 V, 700 ns, 700 ns
MASTER:
Infrared Emitter 880nm Circular Top Mount 2-Pin T-1
Powell:
Sensors, Infrared Sensors, Emitter
Online Components:
Infrared Emitter 880nm Circular Top Mount 2-Pin T-1
Electro Sonic:
Infrared Emitter 880nm Circular Top Mount 2-Pin T-1
额定功率 70 mW
正向电压 1.7 V
波长 880 nm
视角 15°
峰值波长 880 nm
耗散功率 70 mW
上升时间 700 ns
正向电流 50 mA
击穿电压 3 V
正向电压Max 1.7 V
正向电流Max 50 mA
下降时间 700 ns
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 70 mW
安装方式 Through Hole
引脚数 2
封装 T-1
长度 3.94 mm
宽度 3.94 mm
高度 6.35 mm
封装 T-1
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Each
制造应用 Sensing & Instrumentation, Industrial, Signalling
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2014/06/16
ECCN代码 EAR99
HTS代码 8541402000
