SSM2019BRWZRL

自包含的音频前置放大器 Self-Contained Audio Preamplifier

Product Details

The SSM2019 is a latest generation audio preamplifier, combining SSM preamplifier design expertise with advanced processing. The result is excellent audio performance from a monolithic device, requiring only one external gain set resistor or potentiometer. The SSM2019 is further enhanced by unity gain stability.

Key specifications include ultralow noise 1.5 dB noise figure and THD <0.01% at G = 100, complemented by wide bandwidth and high slew rate.

Applications for this low-cost device include microphone preamplifiers and bus summing amplifiers in professional and consumer audio equipment, sonar, and other applications requiring a low noise instrumentation amplifier with high gain capability.

**Applications**

.

Audio Mix Consoles

.

Intercom/Paging Systems

.

Two-Way Radio

.

Sonar

.

Digital Audio Systems

### Features and Benefits

.

Excellent Noise Performance:950 pV/rtHz or 1.5 dB Noise Figure

.

Ultralow THD:<0.01%@G =100 Over the Full Audio Band

.

Wide Bandwidth:1 MHz @G =100

.

High Slew Rate: 20 V/us Typical

.

Unity Gain Stable

.

True Differential Inputs

.

Subaudio 1/f Noise Corner

.

8-Pin Mini-DIP or 16-Pin SOIC

.

Only One External Component Required

.

Very Low Cost

.

Extended Temperature Range:–40ºC to +85ºC
