Conn Socket Strip SKT 6POS 2.54mm Solder ST Thru-Hole Tube
6 位置 插座 0.100"(2.54mm) 通孔 锡
得捷:
CONN RCPT 6POS 0.1 TIN PCB
艾睿:
Reduce safety concerns with this socket strip SS-106-TT-2 header connector from Samtec which will reduce the possibility of accidentally shorting pins when a printed circuit board is being used. This SKT connector&s;s 6 contacts that are made out of beryllium copper and plated with tin over nickel. This is a 1-row connector. It has a straight body orientation. It has a socket type gender. Its pitch is 2.54 mm. This device has a maximum current rating of 1 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This connector has an operating temperature of -55 to 125 °C. SS-106-TT-2 is housed in black polyester. It uses the solder termination method. This product is 15.24 mm long, 4.44 mm tall and 2.54 mm deep.
触点数 6
极性 Female
触点电镀 Tin
排数 1
针脚数 6
额定电流Max 1A/触头
工作温度Max 125 ℃
工作温度Min -55 ℃
接触电阻Max 10 mΩ
安装方式 Through Hole
引脚间距 2.54 mm
长度 15.2 mm
宽度 2.54 mm
高度 4.44 mm
引脚间距 2.54 mm
外壳颜色 Black
颜色 Black
触点材质 Beryllium Copper
外壳材质 Plastic
产品生命周期 Active
包装方式 Tube
制造应用 -
RoHS标准 RoHS Compliant
含铅标准 Lead Free
