SSQ-125-01-S-D

Conn Socket Strip SKT 50POS 2.54mm Solder ST Thru-Hole

50 位置 插座 0.100"（2.54mm） 通孔 镀金

欧时:
SOCKET 50OS 0.1 GOLD PCB

得捷:
CONN RCPT 50POS 0.1 GOLD PCB

艾睿:
Mount this socket strip SSQ-125-01-S-D header connector from Samtec on a jumper post on your PCB to support physical configuration options. This SKT connector&s;s 50 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a socket type gender. This is a 2-row connector. It has a maximum voltage rating of 550 VAC. Its pitch is 2.54 mm. It has a straight body orientation. This device has a maximum current rating of 6.3 A/contact. This product is 64.01 mm long, 8.51 mm tall and 4.95 mm deep. It uses the solder termination method. This connector has an operating temperature of -55 to 125 °C. SSQ-125-01-S-D is housed in black liquid crystal polymer.

安富利:
Conn Socket Strip SKT 50 POS 2.54mm Solder ST Thru-Hole
