Electromechanical Relay SPDT 20A 24VDC 200Ω
Electromechanical Relay 24VDC 200Ohm 20A SPDT52.6x41.1x61.5mm Flange Industrial Relay
Product Highlights
S87R Series
Contact Arrangement = 1 Form C, SPDT, 1 C/O
Contact Current Rating = 20 Amps.
Monostable Coil Magnetic System
Without Coil Suppression Diode
得捷:
RELAY GEN PURPOSE SPDT 20A 24V
贸泽:
Industrial Relays SPDT 20A 24VDC
艾睿:
Electromechanical Relay 24VDC 200Ohm 20A SPDT52.6x41.1x61.5mm Flange Industrial Relay
Chip1Stop:
Electromechanical Relay SPDT 20A 24VDC 200Ohm
Verical:
Power Relay 24VDC 200Ohm 20A SPDT52.6x41.1x61.5mm Flange Industrial Relay
MASTER:
Power Relay 24VDC 200Ohm 20A SPDT52.6x41.1x61.5mm Flange Industrial Relay
Online Components:
Electromechanical Relay 24VDC 200Ohm 20A SPDT52.6x41.1x61.5mm Flange Industrial Relay
Electro Sonic:
Power Relay 24VDC 200Ohm 20A SPDT52.6x41.1x61.5mm Flange Industrial Relay
额定电压AC 277 V
额定电流 20 A
输入电压DC 24.0 V
触点类型 SPDT
功耗 2.9 W
触点额定电流 20 A
线圈电压 24 VDC
线圈电流 120 mA
线圈功率DC 2.90 W
线圈电阻 200 Ω
载流 20.0 A
额定电流Max 20 A
线圈电压DC 24 V
工作温度Max 65 ℃
工作温度Min -10 ℃
额定电压AC Max 277 V
安装方式 Quick Connect
长度 52.6 mm
宽度 52.6 mm
高度 61.5 mm
触点材质 Silver Cadmium Oxide
工作温度 -10℃ ~ 65℃
产品生命周期 Active
包装方式 Tray
RoHS标准 RoHS Compliant
含铅标准 Contains Lead
ELV标准 Non-Compliant
ECCN代码 EAR99
HTS代码 8536410050
