2312 150uF ±10% 4V
150 µF 模制 钽器 4 V 2312(6032 公制) 1.2 欧姆
得捷:
CAP TANT 150UF 10% 4V 2312
立创商城:
150uF ±10% 4V
贸泽:
Tantalum Capacitors - Solid SMD 4volts 150uF 10%
艾睿:
This T491C157K004AT capacitor from Kemet is made from tantalum solid and has a high capacitance value with a low footprint design. It can withstand a voltage of 4 VDC. Its leakage current is 6 μA. This solid capacitor has a maximum operating temperature of 125 °C. It has a tolerance of 10%. Its capacitance value is 150uF. This product is 6 mm long, 2.5 mm tall and 3.2 mm deep.
安富利:
Cap Tant Solid 150uF 4V C CASE 10% 6 X 3.2 X 2.5mm SMD 6032-28 1.2 Ohm 125°C T/R
Verical:
Cap Tant Solid 150uF 4V C CASE 10% 6 X 3.2 X 2.5mm Inward L SMD 6032-28 1.2 Ohm 125C T/R
额定电压DC 4.00 V
电容 150 µF
等效串联电阻ESR 1.2 Ω
容差 ±10 %
产品系列 T491
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 4 V
安装方式 Surface Mount
引脚数 2
封装 6032
长度 6 mm
宽度 3.20 mm
高度 2.5 mm
封装 6032
介质材料 Tantalum
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 500
寿命(小时) 2000h @125℃
RoHS标准 RoHS Compliant
含铅标准 Lead Free
