Microchip### LCD 显示驱动器
显示驱动器,
得捷:
IC DRVR 7 SEG 3 1/2 DIGIT 44MQFP
立创商城:
TC7116CKW
欧时:
Microchip TC7116CKW 3.5 位 ADC, 差分输入, 44引脚 PQFP封装
贸泽:
LCD 驱动器 w/Hold
艾睿:
Single Channel Single ADC Dual Slope 3 1/2Digit LCD 44-Pin MQFP Tray
Allied Electronics:
Microchip TC7116CKW, 3-1/2 digit SerialADC, Differential Input, 44-Pin PQFP
安富利:
ADC Single Dual Slope 3 1/2Digit LCD 44-Pin MQFP Tray
Chip1Stop:
Single ADC Dual Slope 3 1/2Digit LCD 44-Pin MQFP Tray
Verical:
Single Channel Single ADC Dual Slope 3 1/2Digit LCD 44-Pin MQFP Tray
Online Components:
Single Channel Single ADC Dual Slope 3 1/2Digit LCD 44-Pin MQFP Tray
输出电压 700 mV
供电电流 800 µA
电路数 1
耗散功率 10 mW
模数转换数ADC 1
工作温度Max 70 ℃
工作温度Min 0 ℃
耗散功率Max 1000 mW
输入通道数 1
电源电压 9 V
输入电压 0.2V, 2V
安装方式 Surface Mount
引脚数 44
封装 PQFP-44
长度 10.1 mm
宽度 10 mm
高度 2.1 mm
封装 PQFP-44
工作温度 0℃ ~ 70℃
产品生命周期 Active
包装方式 Tray
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99



| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
TC7116CKW Microchip 微芯 | 当前型号 | 当前型号 |
TC7106CKW 微芯 | 完全替代 | TC7116CKW和TC7106CKW的区别 |
TC7116CKW713 微芯 | 类似代替 | TC7116CKW和TC7116CKW713的区别 |
TC7117CLW 微芯 | 功能相似 | TC7116CKW和TC7117CLW的区别 |
