高级LinCMOSE高速8位使用改进的FLASH技术模拟 - 数字转换器 Advanced LinCMOSE HIGH-SPEED 8-BIT ANALOG-TO-DIGITAL CONVERTERS USING MODIFIED FLASH TECHNIQUES
8 位模数转换器 1 输入 1 闪存 20-SSOP
得捷:
IC ADC 8BIT FLASH 20SSOP
立创商城:
TLC0820ACDBR
德州仪器TI:
8-Bit, 392 kSPS ADC Parallel Out, Microprocessor Peripheral, On-Chip Track-and-Hold, Single Channels
贸泽:
Analog to Digital Converters - ADC 8-Bit 392 kSPS Parallel Out
艾睿:
With this TLC0820ACDBR ADC from Texas Instruments you will have no problem converting real world physical signals into a sequence of digital data. This device&s;s digital interface is parallel. This device is based on Semiflash architecture. It has a single-ended input signal. This ADC has a resolution of 8bit. This ADC has an input voltage of 5 V. This ADC has a minimum operating temperature of 0 °C and a maximum of 70 °C.
安富利:
ADC Single Flash 392ksps 8-bit Parallel 20-Pin SSOP T/R
Chip1Stop:
Single Channel Single ADC Semiflash 392ksps 8-bit Parallel 20-Pin SSOP T/R
Verical:
Single Channel Single ADC Semiflash 392ksps 8-bit Parallel 20-Pin SSOP T/R
Win Source:
IC 8 BIT A/D MOD FLASH 20-SSOP
数字逻辑电平 SAR
供电电流 7.50 mA
电路数 1
通道数 1
位数 8
采样率 392 ksps
功耗 37.5 mW
模数转换数ADC 1
输入数 1
工作温度Max 70 ℃
工作温度Min 0 ℃
输入通道数 1
输入电压 5 V
安装方式 Surface Mount
引脚数 20
封装 SSOP-20
长度 7.2 mm
宽度 5.3 mm
高度 1.95 mm
封装 SSOP-20
工作温度 0℃ ~ 70℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TLC0820ACDBR TI 德州仪器 | 当前型号 | 当前型号 |
TLC0820ACN 德州仪器 | 完全替代 | TLC0820ACDBR和TLC0820ACN的区别 |
TLC0820ACFN 德州仪器 | 完全替代 | TLC0820ACDBR和TLC0820ACFN的区别 |
TLC0820ACDW 德州仪器 | 完全替代 | TLC0820ACDBR和TLC0820ACDW的区别 |
