TL3116IPWRG4

模拟比较器 Ultra-Fast Low-Power Precision Comparator

description

The TL3116 is an ultra-fast comparator designed to interface directly to TTL logic while operating

from either a single 5-V power supply or dual ±5-V supplies. The input common-mode voltage extends to the negative rail for ground sensing applications. It features extremely tight offset voltage and high gain for precision applications.

Ultra-Fast Operation. . . 10 ns typ

Low Positive Supply Current

  12.7 mA Typ

Operates From a Single 5-V Supply or From a Split ±5-V Supply

Complementary Outputs

Input Common-Mode Voltage Includes Negative Rail

Low Offset Voltage

No Minimum Slew Rate Requirement

Output Latch Capability

Functional Replacement to the LT1116
