路LinCMOS四路差动比较仪 LinCMOS QUADRUPLE DIFFERENTIAL COMPARATORS
差分 CMOS,MOS,开路漏极,TTL 14-PDIP
得捷:
IC COMPARATOR 4 DIFF 14DIP
立创商城:
TLC374IN
德州仪器TI:
Quad General Purpose LinCMOS™ Differential Comparator
贸泽:
模拟比较器 Quad Differential
艾睿:
The characteristics of this high-gain TLC374IN comparator circuit from Texas Instruments allow it to compare input voltages or currents. Its maximum power dissipation is 500 mW. It has an open drain output. Its typical dual supply voltage is ±3|±5 V, with a minimum of ±1.5 V and maximum of ±8 V. This comparator has a minimum operating temperature of -40 °C and a maximum of 85 °C. This device uses one or two power supplies. It has 4 channels per chip. This device is made with linCMOS technology.
安富利:
Comparator Quad ±8V/16V 14-Pin PDIP Tube
Chip1Stop:
Comparator Quad ±8V/16V 14-Pin PDIP Tube
Verical:
Comparator Quad ±8V/16V 14-Pin PDIP Tube
Win Source:
IC DIFF COMPARATOR QUAD 14-DIP
电源电压DC 3.00V min
输出电流 20 mA
供电电流 0.6 mA
电路数 4
通道数 4
耗散功率 500 mW
静态电流 300 µA
输入补偿电压 5 mV
输入偏置电流 0.005 nA
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 500 mW
电源电压Max 16 V
电源电压Min 3 V
安装方式 Through Hole
引脚数 14
封装 PDIP-14
长度 19.3 mm
宽度 6.35 mm
高度 4.57 mm
封装 PDIP-14
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TLC374IN TI 德州仪器 | 当前型号 | 当前型号 |
TLC374ID 德州仪器 | 完全替代 | TLC374IN和TLC374ID的区别 |
TLV2354IN 德州仪器 | 类似代替 | TLC374IN和TLV2354IN的区别 |
TLC374INE4 德州仪器 | 类似代替 | TLC374IN和TLC374INE4的区别 |
