TLC5540IPWG4

8Bit, 40MSPS ADC Single Ch., Internal S&H, Low Power 24-TSSOP -40℃ to 85℃

8 Bit Analog to Digital Converter 1 Input 1 Flash 24-TSSOP

得捷:
IC ADC 8BIT 40MSPS HS 24-TSSOP

艾睿:
Single Channel Single ADC Semiflash 40Msps 8-bit Parallel 24-Pin TSSOP Tube

安富利:
The TLC5540 is a high-speed, 8-bit analog-to-digital converter ADC that converts at sampling rates up to 40 megasamples per second MSPS. Using a semiflash architecture and CMOS process, the TLC5540 is able to convert at high speeds while still maintaining low power consumption and cost. The analog input bandwidth of 75 MHz typ makes this device an excellent choice for undersampling applications. Internal resistors are provided to generate 2-V full-scale reference voltages from a 5-V supply, thereby reducing external components. The digital outputs can be placed in a high impedance mode. The TLC5540 requires only a single 5-V supply for operation.

Chip1Stop:
Single ADC Semiflash 40Msps 8-bit Parallel 24-Pin TSSOP Tube

Verical:
Single Channel Single ADC Semiflash 40Msps 8-bit Parallel 24-Pin TSSOP Tube
