电容 - 免费, 150毫安,低压差稳压器 Capacitor-Free, 150-mA, Low-Dropout Regulator
PMIC - 稳压器 - 线性 正 固定 1 输出 150mA SOT-23-5
得捷:
IC REG LINEAR 1.2V 150MA SOT23-5
立创商城:
TLV71312PDBVT
德州仪器TI:
150-mA, capacitor-free low-dropout voltage regulator with active output discharge & enable
艾睿:
Keep the energy stable for every system by using this LDO TLV71312PDBVT linear regulator by Texas Instruments. Its typical dropout voltage at current is 0.6@150mA V. It has an overall accuracy of ±1 %. This voltage regulation device&s;s single output can produce a current up to 0.15 A. This will operate at a minimum voltage of 1.4 V and a maximum voltage of 5.5 V, making it easy to control the power in your circuit. With a fixed output that has a voltage of 1.2 V, this is power management at its best. Users like the load regulation of 30mV and line regulation of 5mV. This product will be shipped in tape and reel packaging so that components can be mounted effectively. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C. Its polarity is positive. The maximum dropout voltage is 0.9@150mA V.
安富利:
LDO Regulator Pos 1.2V 0.15A 5-Pin SOT-23 T/R
Chip1Stop:
LDO Regulator Pos 1.2V 0.15A 5-Pin SOT-23 T/R
Verical:
LDO Regulator Pos 1.2V 0.15A 5-Pin SOT-23 T/R
输出接口数 1
输出电压 1.2 V
输出电流 150 mA
静态电流 0.05 mA
输出电容类型 Ceramic
跌落电压 0.6V @150mA
调节输出数 1
输入电压Max 5.5 V
输入电压Min 1.4 V
输出电压Min 1.2 V
输出电流Max 0.15 A
工作温度Max 125 ℃
工作温度Min -40 ℃
精度 ±1 %
输入电压 ≤5.5 V
安装方式 Surface Mount
引脚数 5
封装 SOT-23-5
封装 SOT-23-5
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TLV71312PDBVT TI 德州仪器 | 当前型号 | 当前型号 |
TLV71312PDBVR 德州仪器 | 类似代替 | TLV71312PDBVT和TLV71312PDBVR的区别 |
