TC54系列 4.5V 门限电压 10V 电源 CMOS 电压检测器-SOT-89-3
You will no longer have to worry about under or overvoltages with this voltage detector voltage monitor IC from Technology. This device has a maximum power dissipation of 500 mW. Its maximum power dissipation is 500 mW. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. It has a typical reset threshold voltage of 4.5 V, with a minimum of 4.41 V and a maximum of 4.59 V. This voltage supervisor IC has an operating temperature range of -40 °C to 85 °C. This device has a minimum operating supply voltage of 0.7 V and a maximum of 10 V.
电源电压DC 10.0V max
耗散功率 0.5 W
阈值电压 4.5 V
复位电压Min 4.41 V
复位电压Max 4.59 V
工作温度Max 85 ℃
工作温度Min 40 ℃
耗散功率Max 500 mW
电源电压 10 V
电源电压Max 10 V
电源电压Min 0.7 V
安装方式 Surface Mount
引脚数 4
封装 SOT-89-3
长度 4.6 mm
宽度 2.29 mm
高度 1.6 mm
封装 SOT-89-3
工作温度 -40℃ ~ 85℃
产品生命周期 Unknown
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8542390001
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
TC54VN4502EMB713 Microchip 微芯 | 当前型号 | 当前型号 |
TC54VN4502ECB713 微芯 | 功能相似 | TC54VN4502EMB713和TC54VN4502ECB713的区别 |
